Elongation At Break 300% Heat Shrink Cable End Caps Rohs Compliant 15 KV/mm Dielectric Strength Heat Shrink Wire End Caps
Product Description:
Heat Shrink End Caps are an essential product for sealing and insulation in various industries, particularly in electrical and telecommunications applications. These end caps are designed to provide a tight seal to prevent the ingress of moisture and contaminants, ensuring the safety and longevity of electrical connections. 3M quality
Features:
- Product Name: Heat Shrink End Caps
- Water Absorption: 0.2%
- Operating Temperature: -55°C To +125°C
- Shrink Ratio: 2.5:1
- Elongation At Break: 300%
- Color: Black
- Sealing and Insulation
Technical Parameters:
| Product Name | Heat Shrink End Caps |
| Package Quantity | 100 Pieces |
| Tensile Strength | 10.4 MPa |
| Size Range | 10mm - 250mm |
| Flammability | UL 224 VW-1 |
| Color | Black |
| Dielectric Strength | 15 KV/mm |
| Chemical Resistance | Excellent |
| Material | Polyolefin |
| Operating Temperature | -55°C To +125°C |
| Rohs Compliant | Yes |
Applications:
LONG brand Heat Shrink End Caps
- Electrical wiring connections in buildings and infrastructure
- Automotive and marine electrical systems
- Telecommunications and data networks
- Industrial equipment and machinery
- Solar power installations
Dimensions
| No | Ordinary specification: diameter*high(mm) | Ordinary specification: diameter*high(mm) | Ordinary specification: diameter*high(mm) | Applicable wire outer diameter Φ |
| 1 | 10×30 | 10×40 | 10×50 | 7—9 |
| 2 | 13×30 | 13×40 | 13×80 | 7—12 |
| 3 | 15×40 | 15×50 | 15×100 | 11—13 |
| 4 | 18×40 | 18×50 | 18×100 | 13—15 |
| 5 | 20×40 | 20×60 | 20×100 | 14—18 |
| 6 | 23×40 | 23×50 | 23×60 | 15—20 |
| 7 | 25×40 | 25×60 | 25×65 | 18—22 |
| 8 | 30×50 | 30×70 | 30×100 | 22—27 |
| 9 | 35×50 | 35×70 | 35×100 | 27—30 |
| 10 | 40×60 | 40×70 | 40×120 | 30—35 |
| 11 | 45×60 | 45×70 | 45×120 | 35—40 |
| 12 | 50×70 | 50×80 | 50×120 | 40—45 |
| 13 | 55×70 | 55×80 | 55×120 | 45—50 |
| 14 | 60×80 | 60×90 | | 50—55 |
| 15 | 65×80 | 65×90 | 65×120 | 55—60 |
| 16 | 70×90 | 70×120 | | 60—65 |
| 17 | 75×90 | 75×120 | | 65—70 |
| 18 | 80×100 | 80×120 | | 70—75 |
| 19 | 85×100 | 85×120 | | 75—80 |
| 20 | 90×120 | 90×150 | 140×180 | 80—90 |
| 21 | 95×120 | 95×150 | | 90—95 |
| 22 | 100×130 | 100×160 | 150×180 | 90—95 |
| 23 | 110×130 | 110×160 | 160×180 | 95—110 |
| 24 | 120×130 | 120×160 | | 110—120 |
| 25 | | 130×160 | 130×180 | 120—130 |
| 26 | | 140×160 | 140×180 | 130—140 |
| 27 | | 150×160 | | 140—150 |
| 28 | | 160×160 | | communication cable |
| 29 | Inflatable cap | | | |
| 30 | | | (Patent spring-type) exhaust cap | power cable |
| 31 | | | (Patent bypass valve) exhaust cap | high voltage cable |
Customization:
Customized logo
Min. order: 100
Customized packaging
Min. order: 100
Graphic customization
Min. order: 100
Customization can be made according to customer requirements
Packing and Shipping:
Packaging Details: According to the cap's size
Packing size: 46cm*46cm*45cm
Port: Any ports of China
FAQ
Professional Production Quality is Reliable
Q1 . Which certifications or test reports do you have?
A : We have UL,ROHS and REACH.
Q2 . How to ship my order? Is it safe?
A : For small package, we will send it by Express,such as Fedex, UPS,TNT, DHL and so on.
For big packages, we will send them by Air or By sea or by Train. We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.”
Q3 . What about your delivery time?
A : We have a lot of products in stock. We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.” (Usually is 3-7days).
Q4 . Can you provide samples? Are the samples free?
A : Yes. We can provide samples.
Usually for our standard products with stock, we can supply samples free for testing.
Q5 . Could I put my own logo on it?
A : Sure, of course, we are a professional manufacture and have over 10 years OEM experience.
